BINOCULAR CO-AXIAL MICROSCOPE

Name: BINOCULAR CO-AXIAL MICROSCOPE
Brand: LABCARE INSTRUMENTS & INTERNATIONAL SERVICES
Price: 24000 INR
Availability: InStock

Price 24000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

BINOCULAR CO-AXIAL MICROSCOPE Specification

Spare Parts
Eyepieces, objectives, bulb, fuses, filters available upon request

View Head
Binocular, 360 rotatable

Features
Ergonomic design, achromatic optics, coaxial coarse & fine focus, mechanical stage, variable illumination, dust cover included

Focus System
Coaxial coarse & fine focus knobs

Theory
Binocular Co-Axial Microscope is designed for high precision medical, laboratory, and research work with superior optical performance and ergonomic build.

Drawtube
Binocular, 45 inclined

Sensor
N/A (Optical Viewing with Eyepieces)

Resolution
Optical (determined by objective/eyepiece)

Interface
Standard mechanical controls, optional camera port (not included)

Frame Rate
N/A (not applicable for optical viewing)

Focal Distance
Varies with objective; typically 160mm mechanical tube length

Magnification
40X to 1000X (using 10X eyepiece & 4X, 10X, 40X, 100X objectives)

Dimensions
Approx. 380mm (H) x 200mm (W) x 250mm (D)

Focus Range
Coarse: 30mm, Fine: 0.002mm graduation

Eyepieces
Paired WF10X (Wide Field)

Eyepiece Tube
Binocular, 45 inclined, rotatable 360

Illumination
Built-in 6V/20W halogen lamp or LED lamp, adjustable brightness

Coarse Adjustment Range
30mm approx.

Fine Adjustment Range
0.002mm graduation

Working Stage
Mechanical stage, 125 x 115mm with coaxial X-Y control

Still Image Capture Resolution
N/A (optical microscope, requires additional camera)

Video Capture Resolution
N/A (requires optional camera module)

Image Format
N/A (optical observation, optional for camera adapters)

Interpupillary Distance
55-75mm adjustable

Objective Achromatic
Achromatic 4X, 10X, 40X(S), 100X(S, Oil)

Condenser
NA 1.25 Abbe condenser with iris diaphragm & filter holder

Light Source
Built-in halogen or LED, variable intensity

Voltage
AC 220V/110V 10%, 50/60Hz

Packing
Supplied in sturdy foam and export carton

Body Material
Heavy-duty metal framework with anti-rust coating

Net Weight
Approx. 7 kg

Safety
Fused electrical system, insulated cord

Nosepiece
Quadruple revolving nosepiece with positive click stops

Filter Holder
Blue, green, and yellow filters included

Stage Movement
X-axis: 70mm, Y-axis: 30mm with precision drive

Operating Temperature
10C to 40C

BINOCULAR CO-AXIAL MICROSCOPE Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Gujarat

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
Strong packaging

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About BINOCULAR CO-AXIAL MICROSCOPE

> Two 10x Wide Field Eye -piece.

> 4 nos. Objectives, Parafocal Semi-Plan Achromatic, 4x, 10x, 40x SL and 100x SL Oil immersion.

> Stage : Horizontal Mechanical of size 120 X 125mm min.

> Illumination : LED Light with on/off switch, light intensity regulator and Plano concave mirror attachment suitable for 220V, 50 Hz. AC supply.

> Eye Pieces for Binocular Microscope with coaxial focussing control confirm to IS : 8275:1976 Also available without ISI mark Packaging: Inner Thermocol/Styrofoam Packing and Outer Cardboard Box

Robust Construction for Reliable Performance

Crafted with a heavy-duty metal framework and anti-rust coating, the microscope ensures long-lasting durability, even in rigorous laboratory or clinical environments. Its insulated electrical components and fused safety system add extra protection, making it suitable for busy laboratory schedules and high-frequency use.

Superior Optical and Mechanical Features

This binocular microscope is equipped with achromatic objectives, paired WF10X eyepieces, and a quadruple revolving nosepiece with positive click stops. The mechanical stage offers precise X-Y control, while coaxial coarse and fine focus mechanisms allow for detailed and smooth adjustments during observation. Variable intensity illumination enhances visibility for diverse sample types.

User-Centric Ergonomic Design

Designed with user comfort in mind, the microscope's binocular head is inclined at 45 and fully rotatable, accommodating various viewing positions and reducing neck strain. The adjustable interpupillary distance (55-75mm) ensures a customized viewing experience for users, making it optimal for extended usage.

FAQ's of BINOCULAR CO-AXIAL MICROSCOPE:

Q: How do I operate the coaxial stage movement on this microscope?

A: The microscope features a mechanical stage with X-axis movement of 70mm and Y-axis movement of 30mm, controlled by precision coaxial knobs. These knobs allow for smooth, fine adjustments, enabling you to position your sample accurately for detailed examination.

Q: What are the main advantages of using a binocular co-axial microscope in laboratory settings?

A: This microscope offers ergonomic viewing with reduced eye strain, high precision stage movement, achromatic optics for clear images, and robust durability. Its variable illumination suits a variety of specimens, making it ideal for routine laboratory, research, and clinical tasks.

Q: When should the oil immersion 100X objective be used?

A: The 100X (oil) achromatic objective is used when requiring maximum magnification and resolution, such as observing fine cellular structures in biological samples. Apply immersion oil between the slide and the objective to enhance image clarity during use.

Q: Where can replacement parts and accessories be obtained?

A: Spare eyepieces, objectives, bulbs, fuses, and color filters for the microscope are available upon request from your distributor, exporter, importer, manufacturer, or supplier. Contact your local representative in India or the authorized service provider for genuine components.

Q: What process should I follow for optimal image acquisition with optional camera adapters?

A: To capture still or video images, install an optional camera adapter (not included) onto the microscope's compatible port. Follow the camera manufacturer's setup instructions to achieve optimal focus and resolution, ensuring the sample is well illuminated and properly aligned.

Q: How do I maintain the microscope for long-term usage?

A: Clean all optical parts with lens paper and appropriate cleaning solutions. Cover the microscope with the supplied dust cover when not in use. Store it in a dry, cool environment (10C to 40C operating temperature) and routinely inspect electrical and mechanical parts.

Q: What benefits does the anti-rust coated metal frame provide?

A: The anti-rust coated heavy-duty metal frame enhances the microscope's resistance to corrosion and mechanical wear, extending its operational life and maintaining stable performance even in demanding laboratory or healthcare environments.
