BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE

Send Inquiry

Request To Call Back

BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE

Name: BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE
Brand: LABCARE INSTRUMENTS & INTERNATIONAL SERVICES
Price: 220000 INR
Availability: InStock

Price 220000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE Specification

Spare Parts
Included: Dust cover, Fuse, Immersion oil, Power cord, User manual

Focus System
Coaxial coarse and fine adjustment mechanism

View Head
Trinocular, rotatable

Features
Durable metal frame, anti-fungal optics, wide field observation, ergonomically designed

Theory
Advanced Research Level Microscopy

Drawtube
Trinocular

Sensor
CMOS (when used with camera attachment)

Resolution
Up to 5MP (camera dependent)

Interface
USB (camera dependent), Mechanical controls

Frame Rate
30fps (camera dependent)

Focal Distance
160mm (achromatic objectives)

Magnification
40X-1000X (standard configuration)

Dimensions
Approx. 370mm x 250mm x 390mm

Focus Range
Coarse and Fine Adjustment

Eyepieces
10X Wide Field (pair)

Eyepiece Tube
Inclined at 45, 360 rotatable

Illumination
LED/halogen, built-in, intensity adjustable

Coarse Adjustment Range
30mm

Fine Adjustment Range
0.002mm precision

Working Stage
Double-layer mechanical stage, 140 x 140mm, movement 75 x 50mm

Still Image Capture Resolution
2592x1944 (camera dependent)

Video Capture Resolution
up to Full HD (camera dependent)

Image Format
JPEG, BMP (on camera use)

Interpupillary Distance
55-75mm adjustable

Objective Achromatic
4X, 10X, 40X (S), 100X (Oil, S)

Condenser
Abbe condenser N.A. 1.25 with iris diaphragm and filter holder

Light Source
LED or Halogen, 6V/20W

Body Material
Heavy cast metal base

Finish
Antifungal, powder coated

Power Supply
AC 220V/50Hz

Camera Compatibility
Compatible with digital eyepiece/professional cameras (optional)

Blue Filter
Included for contrast enhancement

Stage Size
140mm x 140mm

Stage Type
Graduated mechanical stage with vernier scale

Stage Movement
X-Y coaxial movement

Nosepiece
Quadruple revolving

Objective Mounting Thread
RMS (Royal Microscopical Society Standard)

BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Gujarat

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
Strong packaging

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE

Optical system Universal Infinite optical system, color corrected plan achromatic optics 4x,10x,20x,40x & 100x oil immersion
Koehler's S-LED, Koehler
illumination, LED intensity Controller, Illumination Eco-energy saving auto cut off, fly eye lens, built[1]in filters Viewing Head Inclined, Two/Three position ergo head
Nosepiece Quintuple nosepiece with slots for POL / DIC
Eyepiece Super wide field 23mm
Mechanical Stage Double Layer, Rackless Ceramic Hard Coated, Stage Lock, Double Slide Holder
Condenser Swing-out abbe, universal Five/Six position
Focusing 3/2 step focusing
DIC Slot for holding DIC plate and prism
Teaching Head Upto 22 person multi viewing attachment
Filters Built-in ND Filters
Packaging: Inner Thermocol/Styrofoam Packing and Outer Cardboard Box.
Optional Packaging: 1) Wooden Box outer cabinet with lock and key (Chargeable).

Advanced Research Performance

Purpose-built for research-level microscopy, the BLXL-PLUS microscope features a quadruple nosepiece, achromatic objectives, and wide field optics. Its coaxial coarse and fine adjustments ensure accurate focusing, and the 140x140mm graduated mechanical stage allows seamless X-Y movement for sample examination.

Trinocular Imaging Flexibility

The trinocular head provides comfortable 45 viewing and full 360 rotation, making prolonged observation ergonomic. The microscope is compatible with optional digital/professional cameras using a standard USB interface, supporting still and video capture (resolution up to 5MP) for documentation and analysis.

Durable, User-Focused Design

Engineered from heavy cast metal with an anti-fungal, powder-coated finish, the BLXL-PLUS stands up to intensive laboratory use. Thoughtful additions-including a blue contrast filter, dust cover, and comprehensive spare parts kit-support reliable, long-term operation in diverse environments.

FAQ's of BLXL-PLUS RESEARCH TRINOCULAR MICROSCOPE:

Q: How is the BLXL-PLUS Trinocular Microscope suitable for advanced research applications?

A: This microscope is tailored for research-level applications due to its quadruple revolving nosepiece, precision achromatic objectives (4X to 100X oil), and wide field 10X eyepieces. Its ergonomic design, trinocular view head, and high stability make it ideal for extensive laboratory studies and documentation.

Q: What digital imaging capabilities does the microscope offer?

A: The trinocular port supports optional digital eyepieces or professional cameras, providing up to 5MP image resolution, USB connectivity, and standard image formats (JPEG, BMP). It enables live video (up to 30fps) or still image capture for thorough sample analysis and record keeping.

Q: When should you use the blue filter included with the microscope?

A: The blue filter should be used when you need to enhance image contrast or correct illumination color, particularly while observing unstained samples under brightfield illumination. It supports clearer, higher-contrast visualization of fine specimen details.

Q: Where can the BLXL-PLUS Microscope be used for optimal performance?

A: Designed for laboratory, academic, or industrial research facilities, the microscope's robust construction and precise controls make it suitable for universities, research institutes, clinical labs, and quality control environments.

Q: What is the process for adjusting the microscope's focus and stage?

A: The microscope utilizes coaxial coarse and fine adjustment mechanisms for precise focusing, offering a range of 30mm (coarse) and 0.002mm (fine, high precision). The double-layer mechanical stage with X-Y coaxial controls and graduated vernier ensures smooth sample positioning and measurement.

Q: How does the anti-fungal, powder-coated finish benefit long-term use?

A: The anti-fungal powder coating protects the microscope's optical components and metal parts from fungal growth and environmental wear, ensuring reliable operation and longevity in humid or challenging laboratory settings.

Q: What accessories and spare parts are included with the microscope?

A: Each unit ships with essential accessories like a dust cover, fuse, immersion oil, power cord, user manual, and a blue filter-along with spare parts to aid in routine maintenance and uninterrupted usage.
