Labtroniks Touch Screen Microprocessor Flame Photometer

Name: Labtroniks Touch Screen Microprocessor Flame Photometer
Brand: LABCARE INSTRUMENTS & INTERNATIONAL SERVICES
Price: 92000.0 INR
Availability: InStock

Price 92000.0 INR/ Unit

Get a Price/Quote

MOQ : -1 Unit

Labtroniks Touch Screen Microprocessor Flame Photometer Specification

Model No
LT 6710

Feature
Touch screen operation, auto ignition, data storage, printer interface, USB port

Temperature Range
Ambient to 800C

Voltage
230 V

Automation Grade
Semi-automatic

Measurement Range
Na: 0-100 ppm, K: 0-100 ppm, Ca: 0-100 ppm, Li: 0-100 ppm

Power Source
230V AC, 50Hz

Frequency
50 Hz

Core Components
Microprocessor, Burner System, Compressor

Capacity
Up to 100 samples/hour

Accuracy
1% for Na, K

Equipment Materials
Powder coated metal with chemical resistant parts

Type
Microprocessor Flame Photometer

Usage
Laboratory, Clinical, and Industrial analysis

Display Type
7-inch TFT Color Touch Screen

Dimension (L*W*H)
420 x 340 x 340 mm

Weight
Approx 15 kg

Printer Interface
Compatible with thermal and dot matrix printers

Ignition System
Automatic with safety interlocks

Operating Temperature
15C to 40C

Sample Aspiration Rate
8 to 10 ml/min

Readout
Concentration and emission intensity

Data Storage
Stores up to 1000 sample results

User Interface
Icon-based graphical user interface

Element Selection
Push button selection for Na, K, Ca, Li

Flame Type
LPG and Air

Calibration
2-point calibration for each element

Gas Supply
Requires LPG (regulator included)

Safety Features
Flame safety device, auto shut-off

Labtroniks Touch Screen Microprocessor Flame Photometer About

TOUCH SCREEN MICROPROCESSOR FLAME PHOTOMETER

The Touch Screen Microprocessor Flame Photometer is a high precision analytical instrument designed for the rapid and accurate determination of alkali and alkaline earth metal elements in liquid samples. Equipped with an advanced touch screen interface and microprocessor controlled operation, it provides reliable, repeatable, and efficient analysis for research, pharmaceutical, agricultural, environmental, and industrial laboratories.

FEATURES

Advanced touch screen display

Microprocessor controlled operation

High sensitivity flame detection system

Accurate elemental analysis

Fast sample measurement

Automatic calibration function

Stable and reliable performance

User friendly interface

Data storage and USB connectivity

Compact and durable construction

APPLICATIONS

Research laboratories

Pharmaceutical industries

Clinical laboratories

Agricultural laboratories

Soil and water analysis

Food and beverage testing

Environmental monitoring

Industrial quality control

BENEFITS

Accurate and repeatable results

Fast analytical performance

Easy operation and maintenance

Reliable long term stability

Suitable for routine laboratory analysis

High productivity and efficient workflow

Advanced Performance and Precision

Equipped with a microprocessor and high-quality burner system, the LT 6710 delivers accurate measurement for Na, K, Ca, and Li with a precision of 1%. The 2-point calibration for each element ensures reliable results, making it indispensable for rigorous laboratory and industrial testing applications.

User-Friendly Touch Screen Interface

The 7-inch TFT color touch screen, along with an intuitive icon-based graphical user interface, simplifies setup and operation. Users can quickly select elements via push buttons and navigate through different functionalities, improving workflow efficiency and minimizing the learning curve for new users.

Robust Safety and Data Management

Safety interlocks, flame safety devices, and auto shut-off mechanisms safeguard users during operation. With the capacity to store and manage up to 1000 sample results, and direct printing options via USB or printer interface, the photometer streamlines data handling and reporting.

FAQ's of Labtroniks Touch Screen Microprocessor Flame Photometer:

Q: How does the Labtroniks Touch Screen Microprocessor Flame Photometer ensure operational safety?

A: This flame photometer integrates multiple safety features, including an automatic ignition system with safety interlocks, a flame safety device, and auto shut-off for enhanced protection during analysis. These safety mechanisms help prevent mishaps associated with flame operation and provide peace of mind during extended usage.

Q: What is the process for calibrating this flame photometer before measurements?

A: The instrument utilizes a 2-point calibration for each element (Na, K, Ca, Li). Users simply follow on-screen prompts to input calibration standards, ensuring precise and reliable readings for every session.

Q: When should data be exported or printed, and how is this achieved?

A: Sample data can be exported or printed at any stage using the integrated printer interface, which supports both thermal and dot matrix printers. The device stores up to 1000 results, making it easy to batch print or export data as needed for record-keeping and quality control.

Q: Where can the Labtroniks LT 6710 be utilized effectively?

A: This model is engineered for use in laboratories, clinical settings, and industrial analysis, thanks to its robust construction, chemical-resistant parts, and precise measurement capabilities. Its versatile design allows it to handle a variety of testing environments with ease.

Q: What is the benefit of using the touch screen and icon-based interface?

A: The 7-inch TFT color touch screen with an icon-based graphical interface streamlines operation, reduces setup time, and helps users of all proficiency levels easily navigate the device's extensive functions.

Q: How is the sample aspiration rate managed and what advantage does it offer?

A: The flame photometer aspirates samples at a rate of 8 to 10 ml/min, which provides consistent sample introduction for optimal accuracy and throughput, making it suitable for high-volume testing environments.

Q: What makes this photometer advantageous for high-throughput laboratories?

A: With the ability to process up to 100 samples per hour, high data storage capacity, semi-automatic features, and compatibility with fast data output devices, the LT 6710 offers significant efficiency improvements for laboratories handling large sample loads.
