Labtroniks Digital Spectrophotometer (Double Display)

Send Inquiry

Request To Call Back

Labtroniks Digital Spectrophotometer (Double Display)

Name: Labtroniks Digital Spectrophotometer (Double Display)
Brand: LABCARE INSTRUMENTS & INTERNATIONAL SERVICES
Price: 34000.0 INR
Availability: InStock

Price 34000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Labtroniks Digital Spectrophotometer (Double Display) Specification

Automation Grade
Semi-automatic

Core Components
Double digital display, optical sensor, light source, sample holder, amplifier circuits

Model No
LT 31/38

Capacity
1 ml to 3 ml cuvette capacity (standard)

Power Source
AC Mains

Accuracy
0.5% T or better

Feature
Double digital display, high accuracy, reliable performance, easy operation

Voltage
220 V AC

Measurement Range
340 nm to 960 nm wavelength

Frequency
50/60 Hz

Equipment Materials
Sturdy ABS Body

Type
Digital Spectrophotometer (Double Display)

Usage
Analysis of solutions in laboratories; quantitative analysis

Display Type
Digital Double Display

Dimension (L*W*H)
420 x 320 x 180 mm (approx.)

Weight
Approx. 7 kg

Wavelength Range
340 nm to 960 nm

Readout System
Digital display for Absorbance & Transmission

Photometric Accuracy
0.02 Abs

Output
Digital direct readout

Calibration
Manual/Direct calibration facility

Detector
Silicon Photodiode

Wavelength Accuracy
2 nm

Light Source
Tungsten Halogen Lamp

Sample Holder
1 cm path length cuvette (standard)

Spectral Bandwidth
5 nm (approx.)

Wavelength Repeatability
1 nm

Photometric Range
-0.3 to 2.5 Abs

About Labtroniks Digital Spectrophotometer (Double Display)

DIGITAL SPECTROPHOTOMETER DOUBLE DISPLAY

The Digital Spectrophotometer Double Display is a precision laboratory instrument designed for accurate measurement of absorbance, transmittance, and concentration in the visible spectrum. Equipped with a dual digital display and advanced electronic control system, it provides fast, reliable, and repeatable analytical results for research, quality control, educational, and industrial laboratory applications.

FEATURES

Dual digital display for easy reading

High measurement accuracy

Stable optical system

Microprocessor based control

Fast response and analysis

Multiple photometric measurement modes

User friendly controls

Compact and durable construction

Low maintenance operation

Reliable long term performance

APPLICATIONS

Research laboratories

Educational institutions

Chemical laboratories

Pharmaceutical laboratories

Food and beverage testing

Environmental analysis

Industrial quality control

Clinical laboratories

BENEFITS

Accurate and repeatable results

Simple and convenient operation

Quick sample analysis

Excellent measurement stability

Long service life

Suitable for routine laboratory testing

Advanced Optical Precision

Equipped with a high-quality optical system, the Labtroniks Digital Spectrophotometer delivers wavelength accuracy of 2 nm and repeatability of 1 nm, ensuring dependable results for every measurement. Its tungsten halogen lamp and silicon photodiode detector guarantee optimal sensitivity for both absorbance and transmission readings.

User-Friendly Double Display

The double digital display design allows simultaneous visualization of absorbance and transmission, streamlining data collection and analysis. Manual or direct calibration facilities further simplify use, making the instrument accessible for technicians and researchers at all levels.

Durability and Versatility

Constructed with a robust ABS body, this spectrophotometer offers longevity in demanding laboratory settings. Its compatibility with standard 1 cm path length cuvettes and a capacity of 1 to 3 ml makes it versatile for various analytic applications, from routine testing to detailed research.

FAQ's of Labtroniks Digital Spectrophotometer (Double Display):

Q: How do you calibrate the Labtroniks Digital Spectrophotometer?

A: Calibration can be performed manually or directly using the built-in calibration facility. This ensures accurate readings across the absorbance and transmission scales, which is essential for precise laboratory analyses.

Q: What types of analysis is this spectrophotometer suitable for?

A: The instrument is designed for quantitative and qualitative analysis of solutions in laboratories. It is ideal for applications requiring measurement within the 340 nm to 960 nm wavelength range, such as chemical, biochemical, and clinical testing.

Q: When should the tungsten halogen lamp be replaced?

A: Replacement is advised if there is noticeable instability in readings or significant decrease in light intensity. Regular preventive maintenance, including lamp checks, will help maintain accuracy and prolong the spectrophotometer's service life.

Q: Where can the Labtroniks Digital Spectrophotometer be used?

A: This model is suitable for analytical laboratories in educational institutions, research centers, medical laboratories, and industrial quality control labs-anywhere precise measurement and robust performance are needed.

Q: What is the process for measuring absorbance or transmission with this device?

A: Insert your prepared sample in a 1 cm path length cuvette, select your desired wavelength, and use the double digital display to read absorbance or transmission directly. The sample holder accommodates cuvettes with a capacity between 1 ml and 3 ml.

Q: What are the operational benefits of the double digital display?

A: The double display enables real-time monitoring of both absorbance and transmission values. This dual readout reduces the chance of error, speeds up the process, and enhances productivity in busy labs.
