X-4 Research Trinocular Microscope, For Laboratory, Halogen

Send Inquiry

Request To Call Back

X-4 Research Trinocular Microscope, For Laboratory, Halogen

Name: X-4 Research Trinocular Microscope, For Laboratory, Halogen
Brand: LABCARE INSTRUMENTS & INTERNATIONAL SERVICES
Price: 40000 INR
Availability: InStock

Price 40000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

X-4 Research Trinocular Microscope, For Laboratory, Halogen Specification

View Head
Trinocular, 45 inclined

Focus System
Coaxial coarse and fine focusing mechanism

Features
Stable body, anti-fungal optics, precise mechanics, ergonomic design

Spare Parts
Fuses, bulb, dust cover, immersion oil

Theory
Research

Drawtube
Trinocular

Sensor
CMOS (Camera optional)

Resolution
Depends on camera (up to 5MP available)

Interface
Standard camera port (C-mount)

Frame Rate
Up to 30 fps (with camera)

Focal Distance
45mm

Magnification
40X to 1600X

Dimensions
375mm x 250mm x 150mm

Focus Range
Coarse & fine focusing system

Eyepieces
Paired 10x wide field eyepiece

Eyepiece Tube
Trinocular (for camera adaptability)

Illumination
Halogen 6V/20W with intensity variable

Coarse Adjustment Range
30mm

Fine Adjustment Range
0.002mm precision

Working Stage
Mechanical moving stage, 140mm x 120mm

Still Image Capture Resolution
Up to 5MP (with camera)

Video Capture Resolution
1280x1024 or as per camera

Image Format
JPEG / BMP / TIFF (with camera)

Interpupillary Distance
55mm to 75mm adjustable

Objective Achromatic
4x, 10x, 40x (SL), 100x (SL, Oil)

Condenser
Abbe condenser, N.A. 1.25 with iris diaphragm

Light Source
Halogen 6V/20W

Nosepiece
Quadruple reversed ball bearing nosepiece

Lamp Housing
Built-in with heat absorbing filter

Stage Coating
Scratch resistant & chemically resistant

Power Supply
220V-240V/50Hz or 110V-120V/60Hz

Anti-Fungal Treatment
Yes, all optical parts

Packing
Thermo-formed case with foam insets for safety

Blue Filter
Included

Stage Movement
75mm x 50mm (X-Y movement)

Head Rotation
360 rotatable head for comfortable sharing

Accessories Included
Dust cover, immersion oil, instruction manual

X-4 Research Trinocular Microscope, For Laboratory, Halogen Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Gujarat

Payment Terms
Paypal, Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Days after Acceptance (DA), Delivery Point (DP), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Western Union, Letter of Credit (L/C)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
Strong packaging

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About X-4 Research Trinocular Microscope, For Laboratory, Halogen

X-4 Research Trinocular Microscope is designed in such a way that a single microscope serves many growing demands which may be placed upon it. Modern style, functional design, advanced engineering and a wide variety of accessories which can be attached to the Microscopes have made our Research Microscopes series a truly versatile range of microscopes.

Precision & Performance for Research Laboratories

Engineered to deliver up to 1600X magnification with achromatic objectives, the X-4 Trinocular Microscope is built for serious research. The advanced focusing system, robust mechanical stage, and ergonomic design support hours of comfortable high-resolution observation. Anti-fungal optics and a stable frame ensure durability and pristine performance even in challenging environments.

Versatile Imaging & Documentation Capabilities

Paired 10x wide field eyepieces and a trinocular head support both direct viewing and digital imaging. The dedicated camera port allows for connection with a range of digital cameras, producing still images up to 5MP and live video up to 30 fps. Supported image formats include JPEG, BMP, and TIFF, making it simple to document and share research findings.

Safety, Durability, and Comprehensive Accessories

All optical surfaces are treated with anti-fungal coatings, and the stage resists chemicals and scratching, extending microscope life. The unit comes packed in a secure, thermo-formed case with foam insets, along with spare fuses, bulbs, a dust cover, and immersion oil. These features help keep the instrument protected and ensure uninterrupted laboratory operation.

FAQ's of X-4 Research Trinocular Microscope, For Laboratory, Halogen:

Q: How does the X-4 Research Trinocular Microscope facilitate digital imaging and video capture?

A: The X-4 microscope features a trinocular head with a standard C-mount camera port, making it compatible with various digital cameras. When connected, it supports resolutions up to 5MP and frame rates up to 30 fps, allowing researchers to capture high-quality still images and live video in JPEG, BMP, or TIFF formats.

Q: What are the main benefits of the microscope's quadruple reversed ball bearing nosepiece?

A: The quadruple reversed nosepiece allows smooth and precise switching between four objective lenses (4x, 10x, 40x, 100x oil). Its ball bearing mechanism ensures secure, accurate alignment and enhances user convenience during frequent magnification changes in research applications.

Q: When is the anti-fungal treatment on optical parts especially advantageous?

A: The anti-fungal treatment applied to all optical components is particularly beneficial in humid or warm laboratory settings, where fungal growth can damage lenses and degrade image quality. This protective measure helps maintain clarity and extend the lifespan of optical surfaces.

Q: Where is the X-4 microscope best used, and what kind of research is it suited for?

A: The X-4 Trinocular Microscope is ideal for laboratories needing precision and versatility, including academic, clinical, and industrial research settings. Its wide magnification range, durable build, and camera adaptability make it suitable for biology, microbiology, pathology, and material science applications.

Q: How should the microscope be maintained to ensure long-term performance?

A: Routine maintenance includes cleaning lenses with appropriate optical cleaning solutions, covering the unit with the provided dust cover when not in use, and storing in the thermo-formed case. Replace lamps and fuses as needed, and use immersion oil only with the 100x objective to prevent contamination.

Q: What process should be followed to adjust illumination during sample observation?

A: Users can modify the brightness using the variable intensity control of the built-in halogen lamp. The Abbe condenser with iris diaphragm further allows precise adjustment of light focus and contrast, ensuring optimal sample visualization at different magnifications.
